Feature

Note

For optimal performance with reComputer, we recommend using 128GB / 256GB / 512GB / 1TB SSDs from Seeed. Since some SSDs on the market may only be compatible with specific JetPack versions which may cause the device to fail to function properly , and this issue is also present with official NVIDIA dev kits.
If you are looking for the version without power adapter, please check out reComputer J2021 without power adapter .

Specification

Jetson Xavier NX System on Module
AI Performance	reComputer J2022, Xavier NX 16GB	reComputer J2021, Xavier NX 8GB
GPU	384-core NVIDIA Volta™ architecture GPU with 48 Tensor Cores
CPU	6-core NVIDIA Carmel Arm®v8.2 64-bit CPU 6MB L2 + 4MB L3
Memory	16 GB 128-bit LPDDR4x 59.7GB/s	8GB 128-bit LPDDR4x 59.7GB/s
Storage	16 GB eMMC 5.1
Video Encoder	2x 4K60 \| 4x 4K30 \| 10x 1080p60 \| 22x 1080p30 (H.265)
Video Decoder	2x 8K30 \| 6x 4K60 \| 12x 4K30 \| 22x 1080p60 \| 44x 1080p30 (H.265)
Carrier Board
Networking	Ethernet	1x RJ45 Gigabit Ethernet Connector (10/100/1000)
Networking	M.2 KEY E	1x M.2 Key E
I/O	USB	4x USB 3.1 Type A Connector； 1x USB Type-C (Device mode)
	CSI Camera	2x CSI Camera (15 pos, 1mm pitch, MIPI CSI-2 )
	Display	1x HDMI Type A; 1x DP
	Fan	1x FAN connector(5V PWM)
	CAN	1x CAN
	Multifunctional Port	1x 40-Pin Expansion header
	RTC	RTC 2-pin RTC socket
Power		9-19V DC
Mechanical	Dimensions (W x D x H)	130mm x 120mm x 58.5mm (with case)
Mechanical	Installation	Desk, wall-mounting
Operating Temperature		-10℃~60℃
Warranty		1 Year

Hardware Overview

reComputer J202 carrier board , included in the full system - reComputer J202 1

Desktop, Wall Mount, Expandable, or Fit in Anywhere

Application

Documents

ECCN/HTS

Part List

Acrylic Cover	1x
Aluminium Frame	1x
Jetson Xavier NX module	1x
Aluminum heatsink with fan	1x
Carrier board	1x
12V/5A(Barrel Jack 5.5/2.5mm) Power Adapter (Power cable not included)	1x
